| Pocket type Nickel-Iron alkaline rechargeable battery |
 |
Pocket type Nickel-Iron alkaline rechargeable battery These batteries have character of high reliability,reasonable price,high capacity,long service life,mo corrosive gas being produced during operation.They can be used as DC power supply for mine tractors,computers and telephone exchanges.TN350 Nickel-Iron rechargeable battery is the only one product which won National silver medal among the same kind of products in china. |
| Models | Nominal |
Nominal Voltage (V) |
Max. Dry Weight (Kg) |
External Dimensions(Max) | Terminal | container Material |
||
| Length | Width | Height | ||||||
| TN10 | 10 | 1.2 | 0.7 | 84 | 38 | 126 | M6 | Engineering plastics |
| TN22-(2) | 22 | 1.2 | 1.3 | 113 | 32 | 217 | M6 | |
| TN30-(2) | 30 | 1.2 | 2.5 | 134 | 68 | 240 | M10x1 | |
| TN40-(2) | 40 | 1.2 | 2.7 | 134 | 68 | 240 | M10x1 | |
| TN45-(2) | 45 | 1.2 | 2.9 | 134 | 68 | 240 | M10x1 | |
| TN50-(2) | 50 | 1.2 | 3.2 | 134 | 70 | 280 | M16 | |
| TN60-(2) | 60 | 1.2 | 3.4 | 134 | 70 | 280 | M16 | |
| TN80-(2) | 80 | 1.2 | 4.5 | 140 | 79 | 360 | M10x1 | |
| TN100-(2) | 100 | 1.2 | 4.9 | 140 | 79 | 360 | M10x1 | |
| TN150-(2) | 150 | 1.2 | 9.5 | 164 | 106 | 345 | M20 | |
| TN200-(2) | 200 | 1.2 | 12 | 167 | 162 | 345 | M20 | |
| TN200-(3) | 200 | 1.2 | 11 | 164 | 106 | 345 | M20 | |
| TN250-(3) | 250 | 1.2 | 15.5 | 276 | 138 | 420 | M16 | |
| TN300-(3) | 300 | 1.2 | 17.5 | 276 | 138 | 450 | M16 | |
| TN400-(2) | 400 | 1.2 | 20 | 276 | 138 | 450 | M16 | |
| TN400-(3) | 400 | 1.2 | 22 | 230 | 170 | 415 | M16 | |
| TN450-(2) | 450 | 1.2 | 22 | 276 | 138 | 450 | M16 | |
| TN500-(2) | 500 | 1.2 | 24 | 276 | 138 | 450 | M16 | |
| TN600-(2) | 600 | 1.2 | 30 | 290 | 174 | 505 | M20 | |
| TN700-(2) | 700 | 1.2 | 33 | 290 | 174 | 505 | M20 | |
| TN800-(2) | 800 | 1.2 | 53 | 398 | 185 | 560 | M20 | |
| TN1000-(2) | 1000 | 1.2 | 55 | 398 | 185 | 560 | M20 | |
 |
 |
