| Pocket type Nickel-cadmium alkaline rechargeable battery |
 |
Pocket type Nickel-cadmium alkaline rechargeable battery,these products Have character of low use cost,wide temperature range,stable discharge voltage,long service life,strong construction,easy maintenance good at over charge and over discharge etc.They can be used as DC power supply for railway(subway),electric power system,communication System,oil chemical industry,iron and steel industry. |
| Models | Nominal Capacity (Ah) |
Nominal Voltage (V) |
Max Weight (Kg) |
External Dimensions(Max) | Terminal | Container Material |
|||
| Length | Width | Height | |||||||
| High rate |
GNG100(D) | 100 | 1.2 | 10 | 167 | 162 | 345 | M20 | Engineering plastics |
| Medium rate |
GNZ30(KPM) | 30 | 1.2 | 3.0 | 134 | 70 | 280 | M16 | |
| GNZ50 | 50 | 1.2 | 3.5 | 134 | 70 | 280 | M16 | ||
| GNZ60 | 60 | 1.2 | 4.7 | 140 | 79 | 370 | M16 | ||
| GNZ75 | 75 | 1.2 | 5.1 | 140 | 79 | 370 | M16 | ||
| GNZ100 | 100 | 1.2 | 7.8 | 164 | 106 | 345 | M20 | ||
| GNZ120 | 120 | 1.2 | 9.5 | 167 | 162 | 345 | M20 | ||
| GNZ150 | 150 | 1.2 | 11.0 | 167 | 162 | 345 | M20 | ||
| GNZ200 | 200 | 1.2 | 16.5 | 276 | 138 | 420 | M16 | ||
| GNZ250 | 250 | 1.2 | 18.5 | 276 | 138 | 450 | M16 | ||
| GNZ300 | 300 | 1.2 | 22.5 | 186 | 171 | 560 | M20 | ||
| GNZ500 | 500 | 1.2 | 26.5 | 290 | 174 | 505 | M20 | ||
| GNZ600 | 600 | 1.2 | 39.5 | 398 | 185 | 560 | M20 | ||
| GNZ700 | 700 | 1.2 | 44.5 | 398 | 185 | 560 | M20 | ||
| GNZ800 | 800 | 1.2 | 55 | 398 | 185 | 560 | M20 | ||
| Low rate |
2GN5(KPL) | 5 | 2.4 | 0.8 | 86 | 53 | 150 | M6 | |
| GN10 | 10 | 1.2 | 0.6 | 84 | 38 | 126 | M6 | ||
| GN22-(2) | 22 | 1.2 | 1.1 | 113 | 32 | 217 | M6 | ||
| GN30-(2) | 30 | 1.2 | 2.3 | 134 | 68 | 240 | M10x1 | ||
| GN40-(2) | 40 | 1.2 | 2.5 | 134 | 68 | 240 | M10x1 | ||
| GN45-(2) | 45 | 1.2 | 2.7 | 134 | 68 | 240 | M10x1 | ||
| GN50-(2) | 50 | 1.2 | 3.0 | 134 | 70 | 280 | M16 | ||
| Gn60-(2) | 60 | 1.2 | 3.2 | 134 | 70 | 280 | M16 | ||
| GN60-(3) (GN60-YL) |
60 | 1.2 | 3.2 | 135 | 49 | 365 | M10x1 | ||
| GN80-(2) | 80 | 1.2 | 4.3 | 140 | 79 | 360 | M10x1 | ||
| GN100 | 100 | 1.2 | 5.5 | 155 | 67 | 360 | M10x1 | Steelcase | |
| GN100-(2) | 100 | 1.2 | 4.7 | 140 | 79 | 360 | M10x1 | Engineering plastics |
|
| GN150-(2) | 150 | 1.2 | 9.0 | 164 | 106 | 345 | M20 | ||
| GN200-(2) | 200 | 1.2 | 11.0 | 167 | 162 | 345 | M20 | ||
| GN200-(3) | 200 | 1.2 | 10 | 164 | 106 | 345 | M20 | ||
| GN250-(2) | 250 | 1.2 | 11.5 | 167 | 162 | 345 | M20 | ||
| GN250-(3) | 250 | 1.2 | 14.0 | 276 | 138 | 418 | M16 | ||
| GN300-(3) | 300 | 1.2 | 16.0 | 276 | 138 | 448 | M16 | ||
| GN400-(2) | 400 | 1.2 | 18.5 | 276 | 138 | 448 | M16 | ||
| GN400-(3) | 400 | 1.2 | 20 | 230 | 170 | 415 | M16 | ||
| GN450-(2) | 450 | 1.2 | 20 | 276 | 138 | 450 | M16 | ||
| GN500-(2) | 500 | 1.2 | 22.0 | 276 | 138 | 450 | M16 | ||
| GN600-(2) | 600 | 1.2 | 28.0 | 290 | 174 | 505 | M20 | ||
| GN700-(2) | 700 | 1.2 | 30.0 | 290 | 174 | 505 | M20 | ||
| GN800-(2) | 800 | 1.2 | 50.0 | 398 | 185 | 560 | M20 | ||
| GN1000-(2) | 1000 | 1.2 | 52.0 | 398 |
185 | 560 | M20 | ||
 |
 |
 |
 |
 |
 |
 |
 |
