Aircraft alkaline rechargeable battery

Nickel-Cadmium aircraft batteries have character of large power density,high energy density,good performance of large discharge current,low internal resistance,long service life,good mechanical intensity,wide temperature range,etc.This kind of batteries are mainly used as emergency power supply for aircraft,Our rechargeable battery packs,20GNG25,20GNG36,have been supplied for Su-27,QJ-11,TU-154,EL-76 as emergency starting,standby power supply for many years.Good performance of the productions,favorable sales service and reasonable price are approved by the users. These batteries can be also used as DC power supply for communication. Large power equipment starting and various instruments.

Storage and maintenance:
The batteries can be stored at the range of temperature from-60°C to +30°C.The service life will be shortened beyond the above mentioned temperature.The stored batteries should be in  discharged condition. Frequent shallow charging/discharging,float charging may make the capacity of the batteries fall down. Through periodical charging and discharging cycles,the performance of the batteries can recover.


Models Nominal
Capacity
(Ah)
Nominal
Voltage
(V)
Max.
Dry Weight(Kg)
External Dimensions
(Max)(mm)

Terminal Container
Material
Length Width Height
XYGN45-(3) 45 1.5 0.93 56 52.2 163 M10 Nylon PA
XYGN45-(3)G 45 1.5 0.93 56 52.2 163 M10
GNG25 25 1.2 1.1 28.5 81 214 M10
GNG36 36 1.2 1.5 36 81 241 M10
GNG36-(2) 36 1.2 1.5 36 81 241 M10
GNG40 40 1.2 1.53 36 81 241 M10
15XYG45-(3) 45 22.5 17.9 434 131 227   SteelCase Pack
15XYG45-(3)G 45 22.5 17.9 434 131 227
20GNG25 25 24 24 370 176 229
20GNG36 36 24 37.2 414 210 269
20GNG36-(2) 36 24 37.2 414 210 269
20GNG40-A 40 24 37.2 418 228 269
20GNG32 32 24 30 432 125 214
20GNC25-(2) 25 24 29.3 320 300 187.5
