Nickel-Cadmium sintered type alkline rechargeable prismatic batteries
(maintenance-free)

Nickel-Cadmium sealed maintenance-free rechargeable prismatic batteries,GNFC20,GNFC30 have characters of low internal resistance,tight construction.good performance of charging and discharging,They are suitable for large power discharging,instant high rate and super high rate discharging. Other feature is that no corrosive gas is produced,no electrolyte is overflowed and carbonated.They can be used as power supply for switch board of power distribution system and emergency system.
Nickel-Cadmium maintenance-free batteries,GNC20-(2), GNC100, GNC120, GNC140, GNC170 have the performance of large power and super high rate discharging. They are used as starting power supply for diesel locomotives,steamers,tanks,airplane,and as DC power supply for other high Current discharge.


Models Nominal
Capacity
(Ah)
Nominal
Voltage
(V)
Max.
Dry Weight(Kg)
External Dimensions
(Max)(mm)

Terminal Container
Material
Length Width Height
GNFC20 20 1.2 1.2 36 81 241 M10 Plastics
GNFC30 30 1.2 1.8 49 80 245 M10
GNFC20-(2) 20 1.2 1.5 37 81 245 M10 Transparent
plastics
GNC100 100 1.2 9 105 163 350 M20
GNC120 120 1.2 9.5 105 163 350 M20
GNC140 140 1.2 10 105 163 350 M20
GNC170 170 1.2 11 105 163 350 M20
