| Nickel-Cadmium cylindrical rechargeable
battery for fire-control emergency light |
 |
Nickel-Cadmium cylindrical rechargeable battery developed by ourselves for fire-control emergency light are of stable discharge voltage,favorable high-temperature and low-temperature performance(temperature range from -18°C~+55°C),efficient charge in high temperature (40±5°C),safe and reliable use. The batteries completely meet technology requirements of GB17945-2000 and have extensively applied to fire-control emergency light. The batteries can be assembled freely according to customer's requirements. |
| Models | Nominal Capacity(mAh) |
Nominal Voltage(V) |
Max.Weight(g) | Max.External Dimensions | |
| Diameter | Height(H) | ||||
| AA600 | 600 | 1.2 | 24 | 14.5 | 50.5 |
| AA700 | 700 | 1.2 | 24 | 14.5 | 50.5 |
| AA800 | 800 | 1.2 | 26 | 14.5 | 50.5 |
| SC1200 | 1200 | 1.2 | 55 | 23.0 | 43.0 |
| SC1300 | 1300 | 1.2 | 55 | 23.0 | 43.0 |
| SC1400 | 1400 | 1.2 | 55 | 23.0 | 43.0 |
| SC1500 | 1500 | 1.2 | 55 | 23.0 | 43.0 |
| SC1600 | 1600 | 1.2 | 60 | 23.0 | 43.0 |
| 5/4SC1800 | 1800 | 1.2 | 80 | 23.0 | 50.0 |
| C1800 | 1800 | 1.2 | 80 | 26.0 | 50.0 |
| C2000 | 2000 | 1.2 | 95 | 26.0 | 50.0 |
| C2200 | 2200 | 1.2 | 95 | 26.0 | 50.0 |
| D3000 | 3000 | 1.2 | 140 | 33.0 | 61.5 |
| D4000 | 4000 | 1.2 | 165 | 33.0 | 61.5 |
| D4500 | 4500 | 1.2 | 165 | 33.0 | 61.5 |
| D5000 | 5000 | 1.2 | 180 | 33.0 | 61.5 |
 |
