MH-Ni sealed cylindrical alkaline storage battery

The MH-Ni batteries have features of superior sealing,operation in all directions without leakage,higher capacity density and energy density,stable voltage,quick charge and discharge,
without "memory effect"and long service life etc. MH-Ni battery can be exchanged with Cd-Ni battery and dry battery,no environment pollution. It is used as DC power sources for communication,lighting,photography,camcorder,police equipment,emergency lights,electronic instruments and apparatus,minicomputers and household electric appliances etc.


Size IEC Nominal
Capacity
(mAh)
Nomonal
Voltage
(V)
Standard Charge Rapid Charge Max External
Dimensions(mm)
Cycle Life
Current
(mA)
Time(h) Current
(mA)
Time(h) Diameter Height(H)
AAA HR11/45 600-700 1.2 120 7 600 1.2 10.5 44.5 500
AA HR15/51 1300-1500 1.2 260 7 1300 1.2 14.5 50.5 500
A HR17/50 1600-1900 1.2 320 7 1600 1.2 17 50.5 500
SC HR23/43 2100-2500 1.2 420 7 2100 1.2 23 43 500
D
6500-8000 1.2 1300 7 6500 1.2 33 61.5 500
