Aircraft Battery

Changhong Aircraft Rechargeable Battery
Changhong aircraft batteries have the characters of big power density,high energy density,low internal resistance,good performance of big discharge current,long service life,good mechanical intensity,wide temperature range,etc. This kind of batteries are mainly used as emergency power supply for aircraft. Our rechargeable battery packs, 20GNG25, 20GNG36, 20GNG40A, 15XYG45-(3), 20GNG25-(2), 20GNC23-(2), 20GNG32, 20GNC23,20GNG40B,20GNC40-(2),have been applied to domestic and foreign civil aviation field as emergency starting,standby power supply for many years. Good performance of the productions,favourable sales service and reasonable prices are approved by our clients These batteries can also be used as DC power supply for communication,big equipment starting and various instruments.

Storage and Maintenance
The batteries can be stored at the temperature range form -60°Cto +30°C. The service life will be shortened beyond the above mentioned temperature. The stored batteries should be in discharged condition. Frequent shallow charging/discharging,float charging make the capacity of the batteries fall down. After periodical charging and discharging,the performance of the batteries can be recovered.










Models Nominal
Capacity
(Ah)
Nominal
Voltage(V)
Max Weight
(Kg)
External Dimensions(Max) Terminal Container
Material
Length Width Height
XYG45-(3) 45 1.5 0.93 56 52.2 163 M10 Nylon PA
XYG45-(3)G 45 1.5 0.93 56 52.2 163 M10
GNC5.5 5.5 1.2 0.28 25 56.5 102 M5
GNC15 15 1.2 0.75 33 54 169 M10
GNC15-(2) 15 1.2 0.6 28.5 60.5 141 M6
GNC23 23 1.2 1.1 35 79 178 M10
GNC23-(2) 23 1.2 1.1 28.5 80 214 M10
GNC23-(3) 23 1.2 1.1 28.5 80 214 M10
GNC25 25 1.2 1.1 28 80 211 M10
GNG25 25 1.2 1.1 28.5 80 214 M10
GNC25-(2) 25 1.2 1.25 40.5 85.5 174 M10
GNC25-(3) 25 1.2 1.1 49 58.5 173 M10
GNG32 32 1.2 1.05 38 58 203 M10
GNG36 36 1.2 1.5 36 80 237 M10
GNG36-(2) 36 1.2 1.5 36 80 237 M10
GNC40 40 1.2 1.5 36 80 237 M10
GNG40 40 1.2 1.5 36 80 237 M10
GNC40-(2) 40 1.2 1.7 38.5 80 268 M10
15XYG45-(3)
45
22.5 17.9 434 131 227 Steel Case Pack
15XYG45-(3)G
45
22.5 17.9 434 131 227
20GNC5.5
5.5
24 8 288 172 123
20GNC15
15
24 17.5 292 168 207
20GNC23-(2)
23
24 24.6 370 180 230
20GNG25A
25
24 24.7 370 175.5 229
20GNC25-(2)
25
24 29.3 293 265 182
20GNG32
32
24 25.5 443 126 214
20GNG36
36
24 37.2 414 209.5 268.5
20GNG36-(2)
36
24 37.2 414 209.5 268.5
20GNG40A
40
24 37.2 418 228 268.5
20GNG40B
40
24 37 303 276 263 SAFT
20GNG40
40
24 37.2 414 209.5 268.5
20GNC23
40
24 25.5 254 248 212 2758
20GNC40-(2)
40
24 43.7 325 275 285 4579
20GNG40C
40
24 36 300 268.4 262 4059
20GNG40D
40
24 36.05 305 253 257 40176\4017CH3
20GNG25
25
24 24.36 370 175.5 229 20HKbH-25-Y3 TU-154
