VRLA SEALED BATTERY FOR INDUSTRY

Features: GFM series VRLA sealed batteries is not necessary to refill with water, all the gases generated during charge are recombined internally, being incorporated again to the electrolyte;safety valves, they release to the outside any overpressure that can be generated internally, so that no emission of gases will occur, safty can be ensured by incorporating an explosion proof filter in the vent hole section;self-discharge, the self-discharge rate has been decreased because of use of pb-ca alloy so that it is unnecessary to charge the battery till half year if place in storehouse at room temperature;safety and sealing, the acid will not leak from the area around the terminal and container, so that the operation can be safe and effective, the battery can be placed horizontally; long service life,long service life has been attained by use of pb-ca alloy, more than 10 years of service life can be expected if use under floating charge.

The vented lead-acid stationary batteries is widely used in the electric power, telecommunication and UPS system, in accordance with the basic parameter and electric performance of DIN standard.GGM stationary battery is a set with a device of acid mist restriction. GGX stationary battery with catalysis plug.Safety, long service life, reliability in service and maintenance easy are typical characteristics.


Basic parameter and electric performance:

Type Rated Voltage(V) Rated Capacity(AH) Max.Overall Dimensions(mm) Weight(Kg)
10hr 5hr 3hr 1hr L W H Total Height
Final Voltage
1.80V 1.77V 1.75V 1.67V
GFM-100 2 100 86 75 56 80 170 222 244 6.6
GFM-200 2 200 172 150 106 103 206 356 385 16
GFM-250 2 250 215 187 132 124 206 356 385 20
GFM-300 2 300 258 225 159 145 206 356 385 22.6
GFM-350 2 350 300 262 185 124 206 472 501 28.5
GFM-420 2 420 360 315 222 145 206 472 501 33
GFM-490 2 490 420 365 259 166 206 472 501 37.5
GFM-600 2 600 516 450 312 145 206 647 676 48.6
GFM-800 2 800 688 600 416 191 210 647 676 65
GFM-1000 2 1000 860 750 520 233 210 647 676 79.7
GFM-1200 2 1200 1032 900 624 275 210 647 676 94.3
GFM-1500 2 1500 1260 1116 744 275 210 798 827 124
GFM-2000 2 2000 1680 1488 992 399 214 773 802 163
GFM-2500 2 2500 2100 1860 1240 487 214 773 802 208
GFM-3000 2 3000 2520 2232 1488 576 214 773 802 248
Note:Specifications are subject to change without prior notice.
