RAIWAY VRLA BATTERIES

Main uses: batteries suitable for diesel locomitives and passenger car e.g.

Features: remarkable large current starting peformance at low or normal temperature;effective shock proof and thermal runaway proof design;desing life:for locomotive running at least 800thousand Km distance;start life:>10000 times; self-discharge:<0.077%/day(25°C); sealing reaction efficiency: 99.9%; charging acceptance ability: charging curcnt>0.15°C; normal temperature start performance:>2100A; low temperature start performance:>1700A;wide temperature range of use:+40°C-- ­40°C.high cranking capabiliy;tubular positives; strict quality control; long life.


Basic parameter and electric performance:

Type Rated Voltage ( v ) Rated Capacity
(Ah)
Max.Overall Dimensions (L*W*H ) (mm ) Total Height(mm) Weight (kg)
C10 C5
NM-420 2 500 420 203*108*360 395 35
4NM-420 8 ---- ---- 449*393*385 415 132
NM-360 2 420 360 170*187*359 369 27
4NM-360 8 ---- ---- 396*393*385 390 116
DM-170 2 170 ---- 85*172*352 363 13
12DM-170 24 ---- ---- 710*420*380 400 185
DM-200 2 200 ---- 102*170*352 363 15
12DM-200 24 ---- ---- 870*315*380 100 200
Note:Specifications are subject to change without prior notice.
