LEAD-ACID TRACTION BATTERY

Main uses: widely used as D.C. power supply for electic propu-lsion vehicles which widely used in railway station, airport, sea-port, coatmine, etc.

Features: LEAD-ACID TRACTION BATTERY, the cells with normal voltage 2V can be connected in series accordi-ng to customers' needs. batteries' containers are made of hard rubber and D-KJ series polypropyl-ene. this series is manufactured of tubular positive plat-ed, pasted negative plated and micro-hole rubber sep-arators.the batterise have features of high anti-vibration strength, long service life, low self-discharge rate, easy installation and uniform electr-ic performance.


Basic parameter and electric performance:
LEAD-ACID TRACTION BATTERIE(PzS Series)

Type Rated Voltage (V) Rated Capacity(Ah) Dimensions (mm) Weight (Kg) Discharging Rate
L W H Wet Dry 5h (1.70v) 3h (1.70v) 0.5h (1.50v)
Current (A) Capacity (Ah) Current (A) Capacity (Ah) Current (A) Capacity (Ah)
2PzS110
2
 110 47
198
370
 8.6 6.7 22 110 31 93 110 55
3PzS165
165 65
12 9.5 33 165 46 139 165 82.5
4PzS220
220 83
15.3 12.6 44 220 62 186 220 110
5PzS275
275 101
18.8 16 55 275 77 232 275 137.5
6PzS330
330 119
22.3 18.3 66 330 93 279 330 165
7PzS385
385 137
25.9 21 77 385 108 325 385 192.5
8PzS440
440 155
29.4 24 88 440 124 372 440 220
2PzS140
140 47
460
 10.5 8.2 28 140 39 118 140 70
3PzS210
210 65
14.7 11.7 42 210 59 177 210 105
4PzS280
280 83
18.9 15.1 56 280 79 236 280 140
5PzS350
350 101
22.9 18.9 70 350 99 295 350 175
6PzS420
420 119
27.6 22.4 84 420 118 355 420 210
7PzS490
490 137
31.8 25.6 98 490 138 414 490 245
8PzS560
560 155
36.5 29.1 112 560 157 473 560 280
2PzS160
160 47
500
 12 9.5 32 160 45 135 160 80
3PzS240
240 65
17 13.4 48 240 67 202 240 120
4PzS320
320 83
22 18 64 320 90 270 320 160
5PzS400
400 101
27 22.2 80 400 112 338 400 200
6PzS480
480 119
32.1 26.3 96 480 135 405 480 240
7PzS560
560 137
37.1 30.3 112 560 157 473 560 280
8PzS640
640 155
42.1 34.4 128 640 180 540 640 320
9PzS720
720 173
47.1 38.4 144 720 203 608 720 360
10PzS800
800 191
52.1 42.2 160 800 225 676 800 400
2PzS200
200 47
605
 15.2 11.6 40 200 56 169 200 100
3PzS300
300 65
21 16.5 60 300 84 253 300 150
4PzS400
400 83
26.7 22.1 80 400 113 338 400 200
5PzS500
500 101
34.1 27.1 100 500 141 422 500 250
6PzS600
600 119
39.9 32.2 120 600 169 507 600 300
7PzS700
700 137
45.2 37.6 140 700 197 591 700 350
8PzS800
800 155
50.9 42.4 160 800 225 676 800 400
9PzS900
900 173
58.6 47.7 180 900 254 760 900 450
10PzS1000
1000 192
64.3 52.7 200 1000 282 845 1000 500
3PzS360
360 65
750
 26 19.7 72 360 101 304 360 180
5PzS600
600 101
41.6 31.6 120 600 169 507 600 300
6PzS720
720 119
49.1 37.8 144 720 203 608 720 360
7PzS840
840 137
56.8 44 168 840 237 710 840 420
8PzS960
960 155
63.3 50 192 960 270 811 960 480
9PzS1080
1080 173
70.8 55 216 1080 304 912 1080 540
10PzS1200
1200 192
78.3 60.4 240 1200 338 1014 1200 600

Basic parameter and electric performance:
LEAD-ACID TRACTION BATTERIE(DG Series)

Type Rated Capacity (5h)(Ah) Voltage (v) Max.Overall Dimensions(mm) Weight(Kg)
L W H Total Height Dry Wet
D-160EA2 160 2 98 180 323 362 12.0 14.8
D-240BB2 240 2 85 161 447 479 13.5 18.5
D-400BG2 400 2 145 160 382 416 19.0 25.0
D-400AG2 400 2 145 160 382 430 24.0 32.0
D-440BJ2 440 2 145 160 445 487 24.0 32.0
D-440VJ2 440 2 145 160 445 480 24.0 32.0
D-440CH4 440 2 145 160 435 475 23.0 31.0
D-440AH2 440 2 145 160 431 469 23.0 31.0
D-550AL4 550 2 176 161 413 495 29.0 38.0
D-550BL2 550 2 176 161 453 478 29.0 38.0
D-550CL4 550 2 176 161 453 495 29.0 38.0
D-550VL2 550 2 176 161 453 475 29.0 38.0
D-620BL2 620 2 176 161 453 478 31.5 40.0
D-620CL4 620 2 176 161 453 495 31.5 40.0
D-620BL4 620 2 176 161 453 478 31.5 40.0
D-480CH4 480 2 145 160 431 475 24.0 31.0
D-250AC2 250 2 136 179 290 331 15.0 19.0
D-250BC2 250 2 136 179 290 310 15.0 19.0
D-250ER2 250 2 136 212 290 332 15.5 20.5
D-250VC2 250 2 136 179 290 315 15.0 19.0
D-330AD2 330 2 136 179 358 390 18.0 23.5
D-330CD2 330 2 136 179 358 390 18.0 23.5
D-330VD2 330 2 136 179 358 383 18.0 23.5
D-395CE4 395 2 136 179 407 448 23.0 29.0
D-440AK2 440 2 175 180 404 448 24.0 31.5
D-440BK2 440 2 175 180 404 433 24.0 31.5
D-515AK2 515 2 175 180 404 448 26.0 34.0
D-515BK2 515 2 175 180 404 433 26.0 34.0
D-560FN2 560 2 127 218 519 551 31.0 40.0
D-290FM2 290 2 91 198 435 467 19.0 23.0
D-440BF2 440 2 145 160 400 435 21.0 29.0
D-480BJ2 480 2 145 160 445 487 24.0 32.0
D-550BL4 550 2 176 161 453 478 29.0 38.0
D-550AP2 550 2 176 161 431 469 29.0 38.0
D-620AL4 620 2 176 161 453 495 31.5 40.0
D-500BQ2 500 2 176 161 382 416 23.5 30.0
D-500BQ4 500 2 176 161 382 416 23.5 30.0
D-500AQ4 500 2 176 161 382 430 23.5 30.0
D-400AH4 400 2 145 160 431 475 24.0 31.0
Note:Specifications are subject to change without prior notice.

Basic parameter and electric performance:
LEAD-ACID TRACTION BATTERIE(VBS Series)

Type Rated Capacity (5h)(Ah) Voltage(v) Max.Overall Dimensions(mm) Weight(Kg)
L H Total Height Dry Wet
6VBS420 420 2 109 495 525
7VBS490 490 2 125 495 525
8VBS560 560 2 141 495 525
9VBS630 630 2 157 495 525
10VBS700 700 2 173 495 525
11VBS770 770 2 189 495 525
12VBS840 840 2 205 495 525
13VBS910 910 2 221 495 525
14VBS980 980 2 237 495 525
15VBS1050 1050 2 253 495 525
2VBS200 200 2 45 690 720
3VBS300 300 2 61 690 720
4VBS400 400 2 77 690 720
5VBS500 500 2 93 690 720
6VBS600 600 2 109 690 720
7VBS700 700 2 125 690 720 33 41
8VBS800 800 2 141 690 720
9VBS900 900 2 157 690 720
10VBS1000 1000 2 173 690 720
11VBS1100 1100 2 189 690 720
12VBS1200 1200 2 205 690 720
13VBS1300 1300 2 221 690 720
14VBS1400 1400 2 237 690 720
15VBS1500 1500 2 253 690 720
Note:Specifications are subject to change without prior notice.
